30 Watt LED Flood Beam Work Light, 3600 Lumens – LG866

The LG866 LED work light combines a 30 W power rating with 3,600 lumens of cold white flood lighting. Its die-cast aluminium housing, 360° swivel bracket and built-in male and female connectors provide a practical lighting solution for demanding work environments. The 9–32 V DC operating range supports 12 V and 24 V electrical systems.

General Characteristics

Housing and Durability

• Housing: die-cast aluminium
• Protection rating: IP69K
• Rated service life: 50,000+ hours
• Vibration tested to 15G

Mounting and Connections

• 360° swivel bracket for adjustable positioning
• Built-in male and female connectors

Approval and Electromagnetic Compatibility

• ECE R10 approved
• EMC: CISPR 25 Class 3 for radio frequency suppression

Technical Light Properties

Beam and Light Output

• Beam pattern: flood beam
• Light output: 3,600 lumens
• Light colour: cold white
• Colour temperature: 6000 K

Electrical Characteristics

Power and LED Configuration

• Nominal lamp power: 30 W
• LED configuration: 20 × 1.5 W high-intensity CREE XTE LEDs

Operating Voltage

• Operating voltage: 9–32 V DC
• Suitable for 12 V and 24 V electrical systems

Dimensions

Lamp Measurements

• Lamp width: 80 mm
• Lamp height: 68 mm
• Lamp thickness: 119 mm
