Headlight Details
A compact 5.5″ round LED headlight offering both High and Low beams plus a position-light feature. Built with an IP69K rated die-cast aluminium housing, it suits a broad 9–32 V system and comes with full E-mark approvals for tractor and industrial fit-ment.
| Description | Details |
|---|---|
| Model / SKU | LG8240EU |
| Voltage Range | 9–32 V DC |
| High Beam Power | 41 W |
| Low Beam Power | 17 W |
| Raw Lumen Output (High) | 4,000 lm |
| Raw Lumen Output (Low) | 1,700 lm |
| Housing / Lens | Die-cast aluminium housing, polycarbonate lens (hard-coated & UV protected) |
Protection & Approvals
| Description | Details |
|---|---|
| Ingress Protection | IP69K – dust and high-pressure wash rated |
| Certifications / E-Mark | ECE R7 · ECE R10 · ECE R112 |
| EMC / Radio-frequency | CISPR 25 Class 4 |
Dimensions
| Description | Details |
|---|---|
| Size (Diameter) | 5.5″ (≈ 139.7 mm) |
