LED Tail Light Rectangular Combination Pair - LG533

LED Tail Light Rectangular Combination Pair - LG533 is a practical and road-ready rear lighting solution for commercial vehicles, trailers, agricultural machinery, and utility fleets. These rectangular LED combination tail lights combine stop light, tail light, indicator, and reflector functions in one compact unit, helping reduce fitting time and rear-end clutter while maintaining reliable visibility in daily use.

Rectangular LED Combination Tail Lights for Trailers and Commercial Vehicles

Designed for 9-33V DC systems, the LG533 is suitable for both 12V and 24V vehicles, making it a flexible choice for mixed fleets. Whether you are upgrading older rear lights or fitting a new vehicle build, these LED tail lights for trailers and commercial vehicles provide dependable multi-function rear lighting in a neat, compact housing.

LED Tail Light Pair with Stop, Tail, Indicator and Reflector Functions

Each lamp integrates the core rear lighting functions needed for everyday road use, including stop, tail, indicator, and an integrated reflector. This all-in-one design makes the LG533 a convenient LED combination rear light pair for trailers, vans, body builds, municipal vehicles, and plant equipment where space, reliability, and compliance all matter.

ECE Compliant LED Tail Lights with EMC Safe Performance

These ECE compliant LED tail lights are approved to ECE R3 for reflector, ECE R6 for indicator, ECE R7 for stop and tail, and ECE R10 for electromagnetic compatibility. With CISPR 25 Class 3 EMC performance, they are designed to operate without causing harmful radio interference, making them suitable for modern vehicles fitted with sensitive electrical and communication systems.

Waterproof LED Tail Lights for 12V and 24V Vehicle Systems

Built with IP67 ingress protection, the LG533 is sealed against dust and temporary water immersion, helping it perform reliably in harsh weather, road spray, and regular wash-down conditions. The multi-voltage 9-33V DC design allows installation across a wide range of vehicles and trailers, from 12V service vans to 24V trucks and commercial transport equipment.

Compact Rectangular LED Rear Lights with Simple Wiring

Measuring 150 x 80 x 21.4 mm, these compact LED rear lights fit neatly into many existing lighting positions while delivering the crisp, instant-on performance expected from modern LED technology. Installation is straightforward thanks to simple colour-coded wiring: White - Earth, Brown - Tail, Red - Brake, and Green - Indicator.

Key Features of the LG533 LED Tail Light Pair

• Multi-voltage 9-33V DC operation for 12V and 24V systems
• Combination tail light with stop, tail, indicator and integrated reflector
• ECE compliant to R3, R6, R7
• ECE R10 approved for EMC protection
• CISPR 25 Class 3 EMC performance
• IP67 rated for dust and water resistance
• Compact dimensions: 150 x 80 x 21.4 mm
• Supplied as a matched pair
• Simple 4-wire connection for straightforward installation
• LED technology for low current draw and long service life
• Flat rectangular design for a clean and modern rear-end finish

Ideal Applications for These LED Rectangular Tail Lights

• Light commercial vehicles and service vans needing compact rear combination lamps
• Boat, car, plant, and general-purpose trailers requiring road-legal LED rear lighting
• Agricultural and construction machinery where robust sealed tail lights help reduce maintenance
• Fleet conversions and bodybuilders standardising on a proven multi-voltage rear lamp solution
• Municipal and utility vehicles where compliant EMC-safe lighting is essential
