240 Watt LED Curved Work Light Bar - LG804

240 Watt LED Curved Work Light Bar – LG804

You need serious illumination for big machinery. This isn't a toy. Our LG804 240-watt curved LED work light bar throws a massive 19,200-lumen wall of light, wrapping around your field of view for total coverage. Engineered for the toughest agricultural and construction environments, it's fully ECE R10 compliant, guaranteeing zero interference with your critical on-board electronics.

Let's talk about the engineering. We built the LG804 around a core of 80 high-intensity 3 W CREE XTE LEDs. That's how we get a proven, consistent output of 19,200 lumens. But raw power isn't the whole story. The gentle curve of the bar is deliberate. It expands your peripheral vision, eliminating the tunnel effect you get with straight bars and simply letting you see more of the job site or field edge. A huge advantage when you're manoeuvring a combine harvester at night or grading a site with an excavator.

This light is built to outlast the machine it's on. Simple as that. The housing is solid die-cast aluminium, acting as both armour and a massive heat sink to protect the electronics. We've sealed the entire unit to an IP68 rating, so you can forget about dust ingress during a dry harvest or water getting in during a high-pressure wash-down. With a service life rated at over 50,000 hours, this is a fit-and-forget solution designed to eliminate downtime from lighting failures.

Here's the thing about adding high-power LEDs to modern machinery: electrical noise. Cheaper lights can wreak havoc with your GPS, telematics, and radio. That's why the LG804 is fully approved to ECE R10 and tested to the punishing EMC CISPR 25 Class 4 standard. Put simply, it runs quiet. No interference, guaranteed. Installation is straightforward on any 12 V or 24 V system, thanks to its wide 9–32 V DC input range, making it a versatile upgrade for your entire mixed fleet of tractors, harvesters, and heavy plant.

Key Features

• Massive Light Output: 19,200 effective lumens from 80 × 3 W high-intensity CREE XTE LEDs.
• Expansive Coverage: Curved design for superior peripheral illumination across a wide work area.
• Versatile Beam Pattern: Combi / Flood beam provides both distance penetration and wide-area coverage.
• Built for Harsh Environments: Robust die-cast aluminium housing and a tough PMMA lens.
• Proven Ingress Protection: Sealed to IP68 for complete resistance to dust and water ingress, even during power washing.
• Zero Electronic Interference: Fully compliant with ECE R10 and the stringent EMC CISPR 25 Class 4 standard.
• Fleet-Wide Compatibility: Wide operating voltage range of 9–32 V DC supports both 12 V and 24 V systems.
• Long-Term Reliability: Engineered for a service life of 50,000+ hours.
• Clean, Natural Light: 6,000 K colour temperature for clear, daylight-like visibility that reduces operator fatigue.
• Substantial Footprint: Measures 1,120 × 114 × 90 mm for broad mounting on large vehicles.

Ideal Applications

• Cab roof or front-weight mounting on large tractors and combine harvesters.
• Roof or ROPS mounting on heavy construction equipment, including excavators, dozers, and graders.
• Primary scene lighting for large utility and service vehicles.
• Illumination for forestry machinery such as harvesters and forwarders.

Why Choose LED-Global Lighting

At LED-Global, we engineer our lighting for the realities of European work sites. We don't believe in hype; we believe in proof. Every component is selected for its durability and performance, and every product is rigorously tested to meet and exceed the standards that matter. You get proven reliability, backed by European engineering and practical, expert support. It's lighting you can depend on.

Work Light Details

240 W LED curved combi work light bar (LG804) — high-output curved bar designed for heavy-duty agricultural, construction and utility vehicle lighting.

Protection

Dimensions

Universal fit — suitable for tractors, harvesters, construction and utility vehicles.
