40 Watt LED Built In Bonnet Work Light - LG895

40 Watt LED Built-In Bonnet Work Light – LG895

This is the straightforward, no-fuss lighting upgrade your John Deere has been waiting for. Engineered as a direct plug-and-play replacement for the original bonnet lights on 6030 and 7030 series tractors, this 40-watt LED work light delivers a powerful 3200-lumen output without causing electronic headaches. It’s built to work, built to last, and is fully approved to ECE R10 with class-leading EMC protection.

When you’re running against the clock, you can’t afford to be fighting with poor visibility or electrical gremlins. The LG895 is designed to solve both problems in one simple swap. It’s a direct fit for the factory housing, replacing the original halogen units with a modern, high-performance LED solution. Forget about cutting wires or fabricating brackets; this light connects directly to your tractor’s existing H9 plug. The job is done in minutes, not hours.

Here’s the thing that really sets it apart: its electrical discipline. This work light is engineered for superior electromagnetic compatibility, compliant with ECE R10 and the stringent CISPR25 CLASS 4 standard. This isn't just a technical detail. It means the light is proven to operate without causing interference on your radio, GPS, or auto-steer systems. Your critical on-board electronics will run as cleanly as they did before, but you’ll have a powerful, reliable beam of light turning night into day.

Built for the realities of modern farming, the LG895 features a rugged die-cast aluminium housing and is sealed to an IP68 rating, offering robust protection against dust and prolonged moisture ingress. It’s built to handle harsh weather and regular wash-downs without failing. With an operating temperature range from -40°C to +60°C, it’s a dependable workhorse through freezing winter nights and long summer days.

Key Features

• Direct OEM Replacement for John Deere bonnet lights (O.E.M. Ref: AL173620).
• Powerful 40 Watt Output from 4 x 10W high-intensity LEDs.
• Impressive 3200 Lumen output for clear, bright illumination.
• Plug & Play Installation with a supplied H9 connector for a perfect fit.
• Superior EMC Protection approved to ECE R10 and CISPR25 CLASS 4 to prevent radio and GPS interference.
• IP68 Rated for complete protection against dust and moisture ingress.
• Durable Construction with a tough die-cast aluminium housing.
• Wide Operating Temperature of -40°C to +60°C ensures all-season reliability.
• Compact Dimensions at 89mm (W) x 108mm (H) x 55mm (D).

Ideal Applications

This light is a direct-fit upgrade for the following John Deere tractor series:

• 6030 Series: 6230, 6330, 6430, 6530, 6630, 6830, 6930, 6534
• 7030 Series: 7130, 7230, 7330, 7430 PR, 7530 PR

Original Equipment names, series numbers & images are quoted for reference purposes only and are not intended to infer that our replacement parts are used as original equipment.

Why Choose LED-Global Lighting

At LED-Global, we focus on what matters: proven reliability and performance you can count on. Our products are designed in Europe for the specific demands of professional users who can’t afford downtime. We don’t oversell. We engineer solutions that work, backed by the certifications to prove it.

• 40 Watt (LED 4 x 10W/PC)
• Size: 89 x 108 x 55mm
• 3200 Lumen
• IP68 (Rated Against Moisture Ingress)
• Operation Temperature: -40C~60C
• EMC Electrical Interference Protection To CISPR25 CLASS 4
• ECE R10 Approved
• Diecast Aluminium Housing
• Supplied with H9 Plug & Play Connector

Dimensions

• Lamp width: 89 mm
• Lamp height: 108 mm
• Lamp thickness: 55 mm

*O.E.M Ref:AL173620

*Compatible with the following:

John Deere

6030 Series

6230, 6330, 6430, 6530, 6630, 6830, 6930, 6534

7030 Series

7230, 7330, 7130, 7530 PR, 7430 PR

*Original Equipment names, series numbers & images are quoted and shown for reference purposes only and are not intended to infer that our replacement parts are used as original equipment
