45W LED-Eckleuchte - vorne links (passt für New Holland) - LG917L

45W LED Corner Light – Front Left (Suits New Holland) – LG917L

This 45W LED front left corner light is engineered as a high-output, OEM-style replacement for New Holland machines that work hard and late. With 9 x 5W OSRAM LEDs delivering 3600 lumen, it gives clear, even light where operators actually need it. Approved to ECE R10 with CISPR 25 Class 4 EMC protection, it’s built for modern agricultural electrics and harsh European weather.

If you’re fighting with dull, ageing corner lamps on your New Holland, this unit solves that. Light output jumps to 3600 lumen at a crisp 6000K colour temperature, so steps, attachments and the near field in front of the cab are far easier to read. Operators see more, react faster, and make fewer mistakes around people, implements and buildings.

The LG917L runs on 10–30V DC, so it drops straight into 12V or 24V systems without fuss. Current draw is low at 2.33A @ 12V and 1.17A @ 24V, which helps protect older looms and keeps alternator load in check. Behind the lens you’ve got proven OSRAM LEDs and a diecast aluminium housing that manages heat and resists vibration on rutted fields or road runs.

This front left LED corner light is sized and shaped to suit New Holland fitment, with an OEM reference of 82014130 for guidance. A built-in H11 connector makes the electrical side straightforward for agricultural electricians and workshop techs. The IP68 rating means the unit is sealed against dust and can withstand prolonged immersion, so power washing and foul weather aren’t a problem when the machine is earning its keep.

Working in winter? The -40°C to +60°C operating range keeps performance stable from frosty starts to hot summer days. The PC (polycarbonate) lens takes stone chips and general abuse better than glass. All of that is wrapped in a compact body measuring 176.3 x 109 x 110.3 mm, so clearance around panels and guards is maintained.

Key Features

• 45W LED output (9 × 5W OSRAM LEDs) – proven LED chips for strong, consistent light and long service life.
• 3600 lumen light output – bright, usable illumination for corners, steps and near-field work areas.
• Operating voltage 10–30V DC – suitable for 12V and 24V agricultural and construction systems.
• Low current draw: 2.33A @ 12V, 1.17A @ 24V – reduces load on wiring and charging systems.
• 6000K colour temperature – clean white light that improves contrast on implements, ground contours and obstacles.
• IP68 ingress protection – sealed against dust and capable of withstanding prolonged immersion, ideal for heavy washdowns and wet conditions.
• Operating temperature -40°C to +60°C – reliable performance from deep winter starts to hot summer operations.
• Diecast aluminium housing – robust body with good heat dissipation for LED longevity.
• PC (polycarbonate) lens – impact-resistant lens to handle stones, branches and daily wear.
• Built-in H11 connector – simplifies installation on compatible looms and reduces wiring time.
• EMC protection to CISPR 25 Class 4 – minimises electrical interference with radios, GPS and control systems.
• ECE R10 approved, RoHS compliant – tested to recognised European standards for electromagnetic compatibility and material safety.
• Dimensions 176.3 × 109 × 110.3 mm – compact footprint to suit OEM-style mounting.
• OEM part reference: Left 82014130 – helps verify suitability for specific New Holland models.*

*Original equipment names and part numbers are for reference only and do not imply the part is supplied as original equipment.

Ideal Applications

• New Holland tractors and harvesters requiring a front left LED corner work light upgrade.
• Agricultural loaders and telehandlers where clear corner and step illumination improves operator safety.
• Yard and livestock work where machines operate close to people, animals and buildings in low light.
• Contractor fleets standardising on reliable, low-maintenance LED lighting across mixed New Holland machinery.
• Municipal and utility equipment using New Holland platforms needing robust, EMC-safe lighting.
