69 Watt LED Fern- und Abblendlicht-Scheinwerfer mit Tagfahrlicht - LG838EU

69 Watt LED High & Low Beam Headlight with DRL – LG838EU

This 69 W LED high and low beam headlight with DRL is built for tractors and agricultural machinery that work hard and late. You get a powerful 5 760 lm cold-white output at 6 000 K, sharp cut-off, and a factory-style H4 plug & play connection. Fully E-approved for road use and EMC-safe for modern electronics, it replaces common OEM units on leading European tractor brands.

Power is nothing without control. That’s why this LG838EU headlight combines a strong 69 W main beam with a dedicated 9 W Daytime Running Light, giving you presence in the day and reach at night. The 6 000 K cold-white light colour cuts through murky weather and dusty yards, so you see edges, implements and obstacles earlier, not just a bright blur in front of you.

The housing is built to live on the front of a tractor, not in a catalogue. A powder-coated aluminium body handles heat and harsh weather, while the polycarbonate lens takes the knocks from gravel, branches and pressure washing. With an IP68 ingress rating, the unit is dust-tight and protected against prolonged immersion, so regular wash-downs, slurry splash and heavy rain are not an issue in normal operation. Vibration tested to 15 G, it stays stable on rough tracks, field ruts and heavy transport work.

Electrically, it’s designed for mixed fleets. The 9 – 32 V DC input covers 12 V and 24 V systems, and the integrated H4 connector makes it essentially a straight swap for many existing halogen units. No ballast boxes. No adapters on most installs. Just a clean plug-in replacement that draws less power for more usable light. That’s especially handy on older machines with tired alternators or packed electrical harnesses.

On the legal and EMC side, it does things properly. The LG838EU is E-approved to ECE R112 (headlamp), ECE R148 (DRL) and ECE R10 (EMC), with CISPR 25 Class 4 compliance for electrical noise. So it won’t upset sensitive tractor electronics, GPS guidance, ISOBUS controls or radios. Dimensions of 165 × 105 × 80 mm mean it fits a wide range of factory bezels and cowls, and it’s a recognised replacement for several OEM references on Case IH, Claas, Fendt, Fiat, Ford/New Holland, Massey Ferguson and Renault models.

Key Features

• 69 W LED main headlight with high & low beam for strong, focused road and field illumination
• Integrated 9 W Daytime Running Light (DRL) for improved daytime visibility and on-road presence
• 5 760 lm luminous flux delivering high-output light for long working days and night operations
• 6 000 K cold-white colour temperature for clear contrast, reduced eye strain and better object definition
• Wide 9 – 32 V DC voltage range suitable for 12 V and 24 V agricultural and industrial electrical systems
• H4 plug & play connector for fast installation and straightforward replacement of many OEM halogen headlights
• IP68 ingress protection – dust-tight and protected against prolonged immersion, ideal for wash-down and harsh outdoor environments
• Powder-coated aluminium housing for robust thermal management and long-term corrosion resistance
• Impact-resistant polycarbonate lens designed to handle stones, branches and yard abuse
• Vibration tested to 15 G to stay reliable on rough ground, headlands and road transport
• E-approved for road use: compliant with ECE R112 (headlamp) and ECE R148 (DRL)
• EMC-safe lighting: compliant with ECE R10 and CISPR 25 Class 4 to protect radios, GPS and control systems
• Compact size – 165 × 105 × 80 mm to suit tight factory housings on modern tractors
• OEM cross references: 3809346M91, 3824712M91, 3713798M91, 3713799M91, 72514546, D45080006 (for reference only; not implying OE supply)

Ideal Applications

• Front headlights on mid- to large-frame tractors working late in tillage, grass and slurry operations
• Replacement headlamp units on Case IH CS series, Claas ARES 540–696 RZ, Fendt 916–930 VARIO and similar machines
• Lighting upgrades on Ford / New Holland 40 Series and TM115–TM190 where more light and lower power draw are needed
• Massey Ferguson 3000, 3100, 3600, 4200, 4300, 6200 and 8200 series tractors needing modern LED performance in existing housings
• Renault 110-14 – 180-94 and Fiat M100 – M160 series agricultural tractors in daily farm, contracting or municipal work
