4 LED Amber Super Slim Grille Warning Strobe – LG774

The LG774 4 LED amber super slim grille warning strobe is a compact, high-visibility warning light designed for tractors, harvesters, construction plant, utility vehicles, recovery vehicles and fleet vans. It delivers a strong amber warning signal from a very small housing, making it ideal where mounting space is limited.

With 12–24 V operation, 21 flash patterns, sync and pairing capability, ECE R65 approval, ECE R10 compliance and IP67 protection, the LG774 is built for professional use on modern working vehicles.

Super Slim Amber Warning Strobe

The LG774 is designed for discreet installation in grilles, bumpers, body trims and compact brackets. Its slim 86 × 15 × 26 mm body allows it to fit into tight spaces without dominating the vehicle front.

The clear lens gives a clean, low-profile look when the strobe is switched off, while the amber flash output provides strong warning visibility when activated.

4 LED High-Visibility Warning Output

The unit uses 4 high-output LEDs with 12 W total power to produce a sharp amber warning signal. This makes it suitable for vehicles working around roads, farms, construction sites, yards and public areas where clear visibility is essential.

The low power draw also makes the LG774 suitable for multi-light installations across the front, rear or sides of a vehicle.

21 Flash Patterns with Sync and Pairing

The LG774 includes 21 selectable flash patterns, allowing installers and fleet managers to match the warning style to site rules, fleet standards or vehicle requirements.

Multiple units can be synced or paired to flash together or alternately, helping create a stronger and more professional warning setup across a grille, bumper, rear body or side panel.

Built for 12 V and 24 V Vehicles

The 12–24 V operating range makes the LG774 suitable for cars, vans, trucks, tractors, agricultural machinery, construction vehicles and plant equipment. This makes it a practical strobe option for mixed fleets and workshop stock.

A 2-way mounting bracket gives flexibility during installation, helping the strobe fit different surfaces, angles and vehicle body designs.

Road-Ready and EMC-Safe

The LG774 is approved to ECE R65 for amber warning light performance and ECE R10 for electromagnetic compatibility. It also meets CISPR 25 Class 3 EMC performance, helping reduce interference with radios, GPS, communication systems and sensitive vehicle electronics.

This makes it suitable for modern vehicles where warning lights must work reliably alongside CANbus systems, telematics and onboard electronics.

IP67 Protection for Harsh Conditions

The IP67 ingress protection rating helps protect the strobe against dust, rain, spray, mud and temporary water exposure. This makes it suitable for agricultural, construction, recovery, utility and municipal vehicles working in harsh outdoor conditions.

Key Features

• 4 LED amber super slim grille warning strobe.
• Compact 86 × 15 × 26 mm body for tight mounting locations.
• 12 W total power with strong amber warning output.
• 12–24 V operation for 12 V and 24 V vehicle systems.
• 21 selectable flash patterns.
• Clear lens with amber flash output.
• 2-way mounting bracket for flexible installation.
• Sync and pairing capability for multi-light setups.
• ECE R65 approved for amber warning performance.
• ECE R10 approved for electromagnetic compatibility.
• CISPR 25 Class 3 EMC performance.
• IP67 protection against dust, rain, spray and temporary water exposure.
• Suitable for grille, bumper, bodywork and compact bracket mounting.

Ideal Applications

• Agricultural tractors, sprayers, harvesters and telehandlers.
• Construction machinery including dumpers, loaders, rollers and excavators.
• Utility vans, highway maintenance vehicles and service fleets.
• Municipal vehicles, sweepers, compact refuse vehicles and council machinery.
• Recovery trucks, breakdown vehicles and roadside assistance fleets.
• Fleet vehicles needing discreet grille-mounted amber warning lights.

Why Choose the LG774 Amber Grille Strobe?

The LG774 is designed for professional users who need compact size, strong warning visibility and reliable compliance. Its slim housing, 21 flash patterns, sync capability, ECE approvals, EMC-safe performance and IP67 construction make it a practical choice for demanding fleet and vehicle safety applications.

For workshops, fleet managers, contractors, farmers and utility operators, this amber grille strobe offers clean installation, strong warning performance and dependable operation in harsh working environments.

Important Fitment Note

Please check mounting position, wiring layout, voltage system, flash pattern requirements and local warning light regulations before installation. The strobe should be securely mounted, correctly fused and tested before road or site use.
