Driving Bar Details
| Description | Details |
|---|---|
| Model / SKU | LG828 |
| Main Beam Power | 96 W (20 × high-intensity LEDs) |
| Position Light Power | 3 W dual-colour LEDs (White / Amber) |
| Voltage Range | 9 – 36 V DC |
| Lumen Output | 12,000 lm (raw) / 9,600 lm (actual) |
| Colour Temperature | 6000 K (Cold White) |
| Beam Range | 1,044 m @ 0.25 lux · 522 m @ 1 lux |
| Lens / Housing | Polycarbonate Lens / Aluminium Heatsink Body |
| Mounting | Adjustable stainless steel mount brackets included |
Protection & Approvals
| Description | Details |
|---|---|
| Ingress Protection | IP69K (water / dust proof) |
| Certifications | ECE R112 · ECE R7 · ECE R10 / EMC CISPR 25 Class 4 |
Dimensions
| Description | Details |
|---|---|
| Size (L × W × H) | 520 × 40.5 × 52.5 mm |
| Weight | 1.2 kg |
