LED Rectangular Marker Light White - LG097 is a compact white LED position/marker lamp designed for clear side and perimeter visibility on commercial vehicles and equipment. Built with a heavy-duty plastic housing and durable PC lens, it is suited for daily use on trucks, trailers, agricultural implements, and construction machinery in demanding on-road and off-road environments.
The lamp uses 6 high-intensity OSRAM LEDs to provide a clean, even white output with low electrical load. It operates on 12-24 V DC, making it suitable for mixed fleets. A sealed construction with IP67 ingress protection helps resist dust, heavy rain, and washdowns, while ECE R10 (e-mark) certification supports EMC-safe operation to help reduce interference with vehicle electronics.
-
Model / SKU: LG097
-
Light type: White LED marker / position light
-
LEDs: 6 pcs OSRAM LEDs
-
Voltage: 12-24 V DC
-
Power consumption: Approx. 0.6 W
-
Ingress protection: IP67
-
Certifications: ECE R10, e-mark
-
Mounting: Flat surface mount with removable bracket
-
Cable: 30 cm pre-wired lead
-
Materials: Heavy-duty plastic housing, PC lens
-
Dimensions: 110 x 40 x 35 mm (Length x Width x Height)
Included: 1x LED rectangular white marker light with mounting bracket and pre-installed 30 cm cable.
Marker Light Details
Protection & Approvals
Dimensions
